Description

A&D® – GF-1200N – Precision Balance

The GF Series incorporates A&D’s unique SHS technology and defies comparison with all others. Revolutionary and patented Super Hybrid Sensor (SHS) technology improves response speed and inimizes maintenance costs. Its unique design provides the fastest response speed in its class – an amazing one-second. SHS combines the best of magnetic force restoration and single point parallelogram load sensing technologies.

Special Features:

• Model is NTEP Class II and meets Pharmacopia Requirements CofC 03-005
• Fast, new Super Hybrid Sensor (SHS) gives you the ultimate in response speed – Just ONE Second!
• Large, bright Vacuum Fluorescent Display – see the display even in the dark
• Percentage, Counting Functions & Comparator functions
• ACAI Counting Function for highly accurate counting
• GLP/GMP/ISO Compliance
• Data Memory Function
• RS-232C Standard
• Standard WinCT Software
• Multiple Weighing Units
• 5 Year Warranty

• Specifications:

  A&D – GF-1200N
  Capacity	1,210g
  Readability	0.01g (0.1 NTEP)
  Pan Size	6.5 x 6.5″ / 165 x 165mm
  Linearity	0.02g
  Stabilization time (typical at FAST)	Approx. 1 second
  Sensitivity drift (10°C to 30°C / 50°F-80°F)	2ppm/°C (When automatic self calibration is not used)
  Operating temperature	5°C to 40°C (41°F to 104°F), 85%RH or less (No condensation)
  Sensing method	Super Hybrid Sensor (SHS); SHS: Patent issued and pending
  Display type	Vacuum Fluorescent Display (VFD)
  Display refresh rate	5 times/second or 10 times/second
  Counting mode	Minimum unit mass: 0.001g Number of samples: 10, 25, 50 or 100 pieces
  Percent mode	Minimum 100% reference mass: 1.0g Minimum 100% display: 0.01%, 0.1%, 1% (Depends on reference mass stored)
  Standard serial I/F	RS-232C Interface with Windows Communication Tools (WinCT: included as CD-ROM)
  External dimensions (W x D x H)	210 x 317 x 86mm / 8.27 x 12.48 x 3.39″
  AC adapter	Confirm that the adapter type is correct for the local voltage and power receptacle
  Power consumption	Approx. 11VA (supplied by AC adapter)
  Net weight	9.5 lb / 4.3 kg
