Crane Scale 20,000X1 lb S-Type NTEP Load Cell, Stainless Steel Indicator, 2 Eye

Description

Crane scale set, calibrate 20,000×1 lb. S Type load cell 20k, NTEP, Alloy steel: Specifications: Rated Output (mV/V): 3.00±0.010 Nonlinearity: ±0.02%FS Hysteresis: ±0.02%FS Repeatability: ±0.01%FS Creep (30 minutes): ±0.02%FS Zero Balance: ±1.00%FS Temperature Effect on Zero: ±0.02%FS/10°C Temperature Effect on Output: ±0.02%FS/10°C Input Resistance: 385±15? Output Resistance: 350±5? Insulation Resistance: ?5000M? Excitation Voltage: 10V(DC/AC) Compensated Temperature Range: -10°C ~ 50°C Operating Temperature Range: -20°C ~ 60°C Safe Overload: 120%FS Cable: 20ft Cable Color Code: Input: Red (+) Black (-) Output: Green (+) White (-) Brecknell SBI-521 Stainless Steel NTEP LED or LCD indicator with Rechargeable Battery and AC Adapter.
