Description

A&D EK-300i – Precision Balance

Everest Compact Balances have been designed to carry on their tradition with enhanced capacities and resolutions. New electronics, wider selection of capacities & resolutions, and remote-zeroing have been included in a low-profile rugged housing. All feature RS-232C standard and are designed to meet Weights and Measures regulations for various countries.

Special Features:

• Overload protection
• Security ring to prevent theft
• Stainless steel weighing pan
• Easy to install rechargeable Ni-MH battery (optional)
• Leveling feet and level bubble for accurate weighing
• Large LCD display (0.63″ / 16 mm height) with back light
• Control zero, mode selection and data output with standard RS-232C
• Counting function with Automatic Counting Accuracy Improvement
• 9 built-in weighing units plus counting & percentage with user priority start-up
• Standard comparator function – HI/OK/LO annunciator
• Full Digital Calibration with optional user definable mass setting
• Conformity to GLP with I.D. and serial number outputs
• Auto Power OFF
• Portable-compact size, light weight, rugged body
• Sealed key panel protection against dust and spills
• Low profile and small footprint for minimal space requirement
• 5 Year Warranty

• Specifications:

  A&D – EK-300i
  Capacity	300 g
  Readability	0.01 g
  Pan Size	4.3″ / 110 mm dia.
  Capacity x Resolution	300 x 0.01 g (Gram) 10.5820 x 0.0005 oz (Decimal Ounce) 9.6450 x 0.0005 ozt (Troy Ounce) 192.90 x 0.01 dwt (Pennyweight) 1500.00 x 0.05 ct (Carat) 80.000 x 0.005 mom (Momme) 4629.8 x 0.2 GN (Grain Unit) 7.9365 x 0.0005 tl (Tael, H.K General)
  Counting Mode	Max. count: 30,000 pcs Min. unit weight: 0.01 g No. of samples: 5, 10, 25, 50 or 100 pieces
  Percent Mode	Min. div.: 0.1% Min.100% weight: 1 g
  Linearity	±0.02 g
  Repeatability (Std.Dev.)	0.01 g
  Sensitivity Drift	20 ppm/°C, 10°C – 30°C / 50°F – 86°F
  Display Type	7 segment LCD with backlight (character height 0.63″ / 16 mm)
  Display Refresh	10 times / second
  Overall dimensions (W x D x H)	7.5 x 8.6 x 2.2″ / 190 x 218 x 55 mm
  Admissible Ambient Temperature	–10°C – 40°C / 14°F – 104°F, less than 85% R.H. (non-condensing)
  Net Weight (approx.)	2.4 lbs / 1.1 kg
  Calibration Mass (default setting)	300 g
  Power	AC adapter or Ni-MH battery pack (option)
  Standard Accessories	Manual, AC adapter
