A&D® – GF-1202A – Precision Balance

The A&D Apollo GF-1202A precision balance has a 1,220 gram capacity with a 0.01 gram readability and has a 6.5 x 6.5 inch (165 x 165mm) pan.

Special Features:

• Quick and accurate results with Smart-SHS weighing sensor (1 second stabilization time)
• Easy set-up and levelling with practical diagnostic check
• Long lasting performance with full metal construction, overload protection and Impact Shock Detection
• Increased security with Password Protection, QuickMin-S and Min-S Alert

• Specifications:

  A&D – GF-1202A
  Capacity	1,220 g
  Readability	0.01 g
  Pan Size	6.5 x 6.5″ (165 x 165mm)
  Repeatability (std dev)	0.01g
  Linearity	±0.02 g
  Accuracy immed.following cal	± 0.010g
  Stabilization time	Approx. 1 sec (approx 0.8 sec for 50 g)
  Sensitivity drift	±2 ppm / °C (10 °C to 30 °C / 50 °F to 86 °F, when automatic self-calibration is OFF)
  Calibration wt	500g, 1000g
  Display	Reverse Backlit LCD (Character height: 17.8 mm)
  Display refresh rate	5 times / second, 10 times / second or 20 times / second
  Units	g (gram), oz (ounces), lb (pound), lb-oz (pound-ounce), ozt (troy ounce), ct (metric carat), mom (momme), dwt (pennyweight), gr (grain), pcs (counting mode), % (percent mode), SG (specific gravity), and a user-programmable unit.
  Counting mode, min unit mass	0.01g
  Counting mode, # of samples	5, 10, 25, 50 or 100 pieces
  Percent mode, min 100% ref mass	1.00g
  Percent mode, min 100% display	0.01%, 0.1% or 1% (depends on the reference mass stored)
  Operating environ ment	5 °C to 40 °C / 41 °F to 104 °F, 85% R.H. or less (no condensation)
  Power supply / consumption	AC adapter / approx. 30 VA
  Communication interface	RS-232C and USB
  Overall Dimensions (WxDxH)	212 (W) x 317 (D) x 93 (H) mm / 8.3 (W) x 12.5 (D) x 3.7 (H) in
  Net weight	Approx. 5 kg / 11 lb
  Shipping Weight	14.3 lbs / 13 x 17 x 11 inches
