A&D GX-22001L Apollo High-Capacity Precision Balance, 22 kg x 0.1 g, Internal Calibration, IP65

Description

A&D GX-22001L Apollo High-Capacity Precision Balance: 22 kg × 0.1 g

The A&D Weighing GX-22001L is the 22 kg model in A&D’s Apollo GX-L series of high-capacity precision balances. It weighs up to 22 kg in 0.1 g steps on a 15.2 × 13.5 in pan, with A&D’s Double Leveraged Super Hybrid Sensor and automatic internal calibration.

Replaces the A&D GP-20K

A&D has discontinued the GP-20K, and the GX-22001L is its successor. If you are looking for an A&D GP-20K, or replacing one, the GX-22001L gives you the same 0.1 g readability, internal calibration, IP65 protection, and swing-arm display as the GP-20K, plus more capacity (22 kg vs. 21 kg) and USB. See the A&D GP-20K reference page for the old specs, or call us at (832) 290-3120.

The IP65 rating lets it work on production floors as well as in labs. Impact shock detection logs heavy drops, tilt detection warns when the balance is off level, and RS-232C and USB are both standard.

Key Features

• 22 kg × 0.1 g; repeatability 0.1 g; linearity ±0.2 g
• Automatic internal calibration; external calibration with 5, 10, or 20 kg
• IP65 dust and water protection
• 15.2 × 13.5 in stainless steel pan
• Double Leveraged Super Hybrid Sensor, readings in about 1.5 seconds
• Impact shock detection with alarm and log; tilt detection
• Large backlit LCD and capacity indicator
• RS-232C and USB standard; free WinCT-UFC software
• Counting, percent, comparator, animal weighing, density, and statistics
• 5-year A&D warranty

Applications

Formulation and Batching

Weigh heavy containers and add ingredients to 0.1 g.

Production and Quality Control

Check fill weights and assemblies, and log results through USB.

Parts Counting

Count large lots of small parts with 0.1 g resolution.

A&D GX-22001L Specifications

What’s in the Box

• A&D GX-22001L balance
• Stainless steel weighing pan
• AC adapter
• USB cable
• Instruction manual

External calibration weights, a printer, and the underhook accessory are not included.

Related A&D GX-L Balances

• A&D GX-12001L, 12 kg × 0.1 g
• A&D GX-32001L, 32 kg × 0.1 g
• A&D GX-32001LN, 32 kg, NTEP Class II
• A&D GX-62001L, 62 kg × 0.1 g

Calibration Options from MNM Scales

Get your GX-22001L calibrated and ready to use on day one. Add either option to your order, and our TDA-certified technicians calibrate it in-house before it ships:

• In-house calibration with certificate, using NIST-tested weights: $250. We calibrate and verify your GX-22001L with NIST-tested weights and include a calibration certificate, so it arrives set up and accurate. Add $250 calibration to cart
• NIST calibration with a NIST-traceable certificate: $595. Full calibration documented on a NIST-traceable certificate, for production, QC programs, and audits that need a paper trail. Add $595 NIST calibration to cart

We also recalibrate scales and balances you already own, by mail-in or in our shop, with on-site service across Houston and the surrounding area. Request calibration or call (832) 290-3120.

Manuals and Documents

The A&D Apollo GX-L data sheet, brochure, and instruction manual are available from A&D Weighing, or call us and we will send them.

Frequently Asked Questions

Is the A&D GX-22001L the replacement for the GP-20K?

Yes. A&D discontinued the GP-20K; the GX-22001L replaces it, with the same 0.1 g readability, internal calibration, IP65 protection, and swing-arm display as the GP-20K, plus more capacity (22 kg vs. 21 kg) and USB.

Does the GX-22001L have internal calibration?

Yes. It calibrates automatically with a built-in weight, and you can also calibrate with 5, 10, or 20 kg external weights.

Can the GX-22001L be used in wet areas?

Yes. It is IP65 rated against dust and water jets.

Which GX-L model is legal for trade?

For selling by weight, choose the NTEP-approved A&D GX-32001LN.

Can MNM Scales calibrate the GX-22001L before it ships?

Yes. Choose in-house calibration with a certificate, using NIST-tested weights, for $250, or NIST calibration with a NIST-traceable certificate for $595.

Why Buy Your A&D Balance from MNM Scales?

MNM Scales is an authorized A&D Weighing dealer and one of the largest scale distributors in the country, with one of the largest selections of balances and scales in every category. We offer free shipping in the continental U.S., in-house calibration and certificates, and real help choosing the right model from our Houston-area team. Wholesale and volume buyers can contact us for a quote.
